Driver Convenience

Emergency services call system

Handsfree tailgate opening/closing

Entertainment

DAB Digital radio

Low speed exterior sound speaker

Steering wheel remote infotainment controls

Exterior Body Features

Fixed panoramic sunroof with high gloss black rear roof panel

Front metal tread plates engraved with EC40

High gloss black front bumper deco

High gloss black front grille strikethrough and ironmark

High gloss black rear model and engine and volvo logo badges

High gloss black rear skid plate

High gloss black tailgate spoiler

High gloss black window trim

Integrated roof rails in black

Rear side wing doors

Roof antenna

Visible VIN plate

Interior Features

12V socket in front tunnel console

3 Spoke tailored steering wheel with chrome trim

Centre console cupholders and storage

Charcoal headlining

Connect suede textile/microtech upholstery

Flexible load floor and grocery bag holder

Front door pocket illumination

Front load compartment (31 litres)

Glovebox bag hook

Height/reach adjustable steering column

High gloss black centre tunnel deco

Integrated waste bin

Load cover

Load protection net

One pedal drive mode

Rear armrest with cupholder

Rear coat hook

Sports steering wheel

Underfloor cargo storage

Packs

Climate pack - EC40/EX40

Safety

3x3 point rear seatbelts

City safety with steering support with Pedestrian + cyclist + front collision warning with full auto brake and rear auto brake

Driver and passenger airbags

Drivers knee airbag

First aid kit

Front and outer rear seatbelt reminder and pretensioners

Front seats SIPS airbags

IC (Inflatable Curtains) - Full Length

ISOFIX attachment (Front passenger and Rear outer seats)

Passenger airbag cut-off device

Power child locks on rear doors

Road sign information display

Run off Road Mitigation

SIPS (Side Impact Protection System)

Slippery road and hazard light alert

Tyre pressure monitoring system

Warning triangle

WHIPS whiplash protection system - front

Security

2 x Key integrated remote control central locking including recharging port with deadlocking system and auto open/close power windows

Anti-theft alarm including immobiliser/volume sensor + level sensor

Care key with user defined top speed

Convenient entry and start

Keyless drive with keyless entry and keyless start

Locking wheel nuts

Private locking for tailgate

Remote door locking and unlocking

Electric Vehicle Data

Battery Capacity in kWh	82
Battery Charging Scenario 1 - Charge Time (Mins)	2520
Battery Charging Scenario 1 - Percentage Change	0-100
Battery Charging Scenario 1 - Power Supply - kW	2.3
Battery Charging Scenario 2 - Charge Time (Mins)	1500
Battery Charging Scenario 2 - Percentage Change	0-100
Battery Charging Scenario 2 - Power Supply - kW	3.7
Battery Charging Scenario 3 - Charge Time (Mins)	780
Battery Charging Scenario 3 - Percentage Change	0-100
Battery Charging Scenario 3 - Power Supply - kW	7.4
Battery Charging Scenario 4 - Charge Time (Mins)	28
Battery Charging Scenario 4 - Percentage Change	10-80
Battery Charging Scenario 4 - Power Supply - kW	205
Battery Leased	False
Battery Type	Lithium-ion
Charging Port Location	Left Side Rear
Coupler/Connector Type	CCS Type 2
Maximum Charging Rate - kW	205
Standard manufacturers Battery warranty - Mileage	100000
Standard manufacturers Battery warranty - Years	8
Usable Battery Capacity	79
WLTP - EC (kWh/100km) - Comb - TEH	18.7
WLTP - EC (kWh/100km) - Comb - TEL	17.6
WLTP - EC (miles/kWh) - Comb - TEH	3.3
WLTP - EC (miles/kWh) - Comb - TEL	3.5
WLTP - Pure Electric Range (km) - Comb	542
WLTP - Pure Electric Range (km) - Comb - TEH	510
WLTP - Pure Electric Range (km) - Comb - TEL	542
WLTP - Pure Electric Range (miles) - Comb	336.8
WLTP - Pure Electric Range (miles) - Comb - TEH	316.9
WLTP - Pure Electric Range (miles) - Comb - TEL	336.8

Emissions - ICE

CO2 (g/km)	0

Engine and Drive Train

CC	1
Gears	1 SPEED
Transmission	AUTO

Fuel Consumption - ICE

EC Directive 1999/100/EC Applies	False

General

Alternative Fuel Qualifying	True
Badge Engine CC	0.0
Badge Power	442
Coin Description	325kW Twin Motor Performance
Coin Series	Plus Black Edition
Generation Mark	1
Insurance Group 1 - 50 Effective January 07	41E
Man Corrosion Perforation Guarantee - Years	12
Manufacturers Paintwork Guarantee - Years	3
NCAP Adult Occupant Protection %	92
NCAP Child Occupant Protection %	89
NCAP Overall Rating - Effective February 09	5
NCAP Pedestrian Protection %	70
NCAP Safety Assist %	89
Safety Concerns	False
Service Interval Frequency - Months	24
Service Interval Mileage	18000
Special Edition	False
Special Order	False
Standard manufacturers warranty - Mileage	60000
Standard manufacturers warranty - Years	3
Vehicle Homologation Class	M1

Performance

0 to 62 mph (secs)	4.6
Engine Power - BHP	442
Engine Power - KW	325
Engine Power - PS	True
Engine Torque - LBS.FT	494
Engine Torque - MKG	68.3
Engine Torque - NM	670
Top Speed	112

Test Cycles

Emissions Test Cycle	WLTP
RDE Certification Level	N/A

Tyres

Alloys	True
Space Saver	False
Tyre Size Front	235/45 R20
Tyre Size Rear	255/40 R20
Tyre Size Spare	TYRE REPAIR KIT
Wheel Style	5 SPOKE
Wheel Type	20" ALLOY

Vehicle Dimensions

Height	1596
Length	4440
Wheelbase	2702
Width	1938
Width (including mirrors)	2034

Weight and Capacities

Gross Vehicle Weight	2620
Luggage Capacity (Seats Down)	1310
Luggage Capacity (Seats Up)	404
Max. Loading Weight	510
Max. Roof Load	75
Max. Towing Weight - Braked	1800
Max. Towing Weight - Unbraked	750
Minimum Kerbweight	2110
No. of Seats	5
Turning Circle - Kerb to Kerb	11.4
